100M ADSS Fiber Optic Cable12/24/48/96 Core SM G652D Optical Cable Fiber Count 2-288 Jacket Material PE

01

Product description

The ADSS (All-Dielectric Self-Supporting) fiber optic cable is a high-performance outdoor optical cable designed for aerial installation without the need for metallic support elements. Built with a loose tube stranded structure, this cable is ideal for long-span applications, especially where power line interference or lightning risk is a concern. Constructed with non-metallic components, including FRP (Fiber Reinforced Plastic) central strength members and 100% genuine aramid yarn (no polyester fiber blended), ADSS cable delivers exceptional tensile strength and weather resistance. It is suitable for various span lengths, typically ranging from 50m to 500m or more, depending on the fiber count and design tension.

02

Key features

  • All-dielectric design Safe for installation along power lines; immune to electromagnetic interference
  • Self-supporting aerial structure No need for lashing or messenger wire
  • High-strength aramid yarn Ensures superior tensile performance across span distances
  • Loose tube stranded construction Offers mechanical stability and protection for the fibers
  • UV and weather-resistant Suitable for long-term outdoor exposure in harsh environments
  • Flexible span design Can be customized for short, medium, or long spans based on project needs

03

Applications

  • Overhead aerial fiber network installations
  • Transmission and distribution line communication systems
  • Smart grid and electrical utility networks
  • Remote video surveillance and monitoring
  • Rural broadband access and long-span FTTH backbones
  • EMC-sensitive installations (no grounding required)

04

Technical specifications

ParameterDetails
Fiber TypeSingle Mode (G.652D / G.657A1 / G.657A2)
Fiber Count2 to 144 cores (customizable)
StructureLoose tube stranded around FRP central strength member
Strength MemberCentral FRP rod + full aramid yarn (no polyester blend)
Jacket MaterialHDPE (High-Density Polyethylene) or LSZH (optional)
Outer Diameter10 – 16 mm (depends on fiber count and design)
Span Distance50m / 100m / 200m / 300m / up to 500m+ (design as per requirement)
Installation MethodAerial self-supporting (no additional support needed)
Operating Temperature-40°C to +70°C
ComplianceIEC 60794-1-2, ISO/IEC 11801, TIA/EIA-568, RoHS

Other fiber counts, sheath materials and drum lengths are produced to order — send us the line drawing or the standard you work to.

05

Why buy it from Ebocom

01

ADSS produced in-house from loose tube to final sheathing, with span design support for each project

02

In-house performance laboratory attenuation, tensile, crush, temperature cycling and water penetration testing on every batch

03

Production capacity up to 100 km per day, so large project quantities keep their delivery date

04

Full OEM / ODM support fiber type, sheath material, print marking, drum length and packaging to your specification

05

Export experience across telecom operators, power utilities and distributors worldwide, with document and logistics support
