Home/Products/Patch Cord/2.0mm Fiber Optic Patch Cable
PATCH CORD
Patch Cord
01
SC/UPC-SC/UPC Duplex Multimode OM3 2.0mm Fiber Optic Patch Cable Fiber splicing cables are ideal for supporting fiber optic applications in high-speed telecommunications networks. It can provide OM1, OM2, OM3, OM4, OM5, or OS2 optical fibers to meet the requirements of Gigabit Ethernet, 10-Gigabit Ethernet, and high-speed Fibre Channel. Each terminal is subjected to rigorous parametric testing to ensure the highest network performance.
02
03
04
| Item | SM(Single Mode) MM(Multimode) |
|---|---|
| Fiber Cable Type | G652/G655/G657 OM1 OM2/OM3/OM4 |
| Fiber Diameter (um) | 9/125 62.5/125 50/125 |
| Cable OD (mm) | 0.9/1.6/1.8/2.0/2.4/3.0 |
| End-face Type | PC UPC APC UPC UPC |
| Typical Insertion Loss (dB) | <0.2 <0.15 <0.2 <0.1 <0.1 |
| Return Loss (dB) | >45 >50 >60 / |
| Insert-pull Test (dB) | <0.2 <0.3 <0.15 |
| Interchangeability (dB) | <0.1 <0.15 <0.1 |
| Anti-tensile Force (N) | >70 |
| Temperature Range (ºC) | -40~+80 |
Other fiber counts, sheath materials and drum lengths are produced to order — send us the line drawing or the standard you work to.
05
Dust-controlled patch cord workshop with 100% end-face inspection and optical testing
In-house performance laboratory attenuation, tensile, crush, temperature cycling and water penetration testing on every batch
Production capacity up to 100 km per day, so large project quantities keep their delivery date
Full OEM / ODM support fiber type, sheath material, print marking, drum length and packaging to your specification
Export experience across telecom operators, power utilities and distributors worldwide, with document and logistics support
