GYTA53 Direct Buried Fiber Optic Cable 2-144 Core Double Armored

Name: GYTA53 Direct Buried Fiber Optic Cable 2-144 Core Double Armored
Brand: Ebocom

2–144 core · armored

2–144 Core DuctAerialDirect burial

Request a quote All products

GYTA53 Direct Buried Fiber Optic Cable 2-144 Core Double Armored

Product description

The GYTA53 cable is specifically engineered for direct buried (underground) installations where high mechanical protection is mandatory. Designed to withstand extreme pressure and rodent attacks, it features a sophisticated Double-Armored and Double-Jacket construction. At its core, the fibers are housed in high-modulus loose tubes filled with a water-resistant compound. The structure includes an aluminum tape (APL) moisture barrier, an inner PE sheath, and a longitudinal corrugated steel tape (PSP) armor, all encased in a rugged outer PE jacket. This multi-layer defense makes the GYTA53 the “gold standard” for harsh underground environments.

Key features

Double Armoring for Maximum Protection The combination of Aluminum tape (moisture barrier) and Steel tape (mechanical protection) ensures the cable can withstand heavy soil pressure.
Superior Crush & Rodent Resistance The corrugated steel tape (PSP) provides a hard physical barrier against rodents and accidental mechanical impact during excavation.
Excellent Water Blocking Dual-layer moisture barriers and water-blocking compounds prevent "water-treeing" and protect signal integrity over decades.
High Tensile Strength A solid central strength member (FRP or Steel wire) ensures the cable maintains its structural integrity during high-tension pulling.
Direct Buried Ready Engineered specifically for underground use without the need for additional conduits or ducting.

Applications

Underground Direct Burial Primary choice for long-distance communication lines where trenching is used and no duct is available.
Rodent-Prone Areas The steel armor is essential for protecting fiber in agricultural or forest zones where cable-gnawing animals are present.
Harsh Soil Conditions Suitable for areas with high moisture, acidity, or rocky soil that requires extra chemical and physical resistance.
Inter-City Backbone Networks Provides the high-capacity, durable link required for regional telecommunication hubs.
Industrial & Mining Sites Reliable data transmission in heavy industrial zones with high mechanical vibrations and soil movement.

Technical specifications

Parameter	Value
Feature	Specification Details
Fiber Count	2 to 144 Cores (G.652.D / G.655 / G.657.A)
Cable Type	GYTA53 (Outdoor Direct Buried)
Armor Layer 1	APL (Aluminum Polyethylene Laminate)
Armor Layer 2	PSP (Corrugated Steel Tape)
Jacket Structure	Double PE (Inner Jacket + Outer Jacket)
Central Strength Member	Phosphated Steel Wire / FRP
Crush Resistance	3000 N / 100mm (Long Term)
Tensile Strength	1500 N / 3000 N (Customizable)
Operating Temp	-40°C to +70°C

Other fiber counts, sheath materials and drum lengths are produced to order — send us the line drawing or the standard you work to.

Why buy it from Ebocom

Complete outdoor cable line secondary coating, stranding, armoring and sheathing all under one roof

In-house performance laboratory attenuation, tensile, crush, temperature cycling and water penetration testing on every batch

Production capacity up to 100 km per day, so large project quantities keep their delivery date

Full OEM / ODM support fiber type, sheath material, print marking, drum length and packaging to your specification

Export experience across telecom operators, power utilities and distributors worldwide, with document and logistics support
