Home/Products/Indoor Cable/Factory GJFJH Indoor Optic Fiber Cable Tight Buffer 2 4 12 24 Core SM MM OM1 OM2 OM3 For Internet

GJFJH

Factory GJFJH Indoor Optic Fiber Cable Tight Buffer 2 4 12 24 Core SM MM OM1 OM2 OM3 For Internet

Name: Factory GJFJH Indoor Optic Fiber Cable Tight Buffer 2 4 12 24 Core SM MM OM1 OM2 OM3 For Internet
Brand: Ebocom

2–24 core · OM1 · tight buffer

2–24 Core Indoor

Request a quote All products

Factory GJFJH Indoor Optic Fiber Cable Tight Buffer 2 4 12 24 Core SM MM OM1 OM2 OM3 For Internet

Product description

Indoor fiber optic cables are designed for connecting devices such as computers and switches within buildings. Compared to outdoor cables, indoor cables have a lighter construction and lower tensile strength. These cables require a flame-retardant jacket to meet safety standards and are available in different grades, such as LSZH (Low Smoke Zero Halogen) or PVC depending on their location within a building. They are ideal for short-distance, high-speed applications such as local area networks (LANs) and internet connections.

Key features

Common Applications Interconnecting equipment within buildings, such as servers, switches, and user equipment. Horizontal and vertical backbone subsystems. Patch cords and distribution cables.

Applications

Indoor installations Tight buffer optical cables are commonly used in indoor applications such as LAN (Local Area Network) connectivity, data centers, and premise wiring where frequent handling and flexibility are required.
Direct connectorization The direct termination capability of tight buffer cables makes them suitable for applications that require fast and convenient field terminations, such as patch cords, pigtails, or fiber optic connectors.
Broadcast and multimedia These cables are also used in various audio/video transmission systems, television studios, and multimedia installations that demand reliable and high-quality signal transmissions.

Technical specifications

Parameter	Value
Fiber Type	G.652D single mode or OM1–OM5 multimode
Fiber Count	2 to 24 core
Structure	Tight buffered 900 µm
Strength Member	Aramid yarn
Jacket	LSZH (low smoke zero halogen) or PVC
Flame Rating	IEC 60332-1 / -3 flame retardant
Bend Radius	10 × cable diameter (static)
Operating Temperature	-20°C to +60°C
Standards	IEC 60794-2 / ISO/IEC 11801 / TIA-568

Other fiber counts, sheath materials and drum lengths are produced to order — send us the line drawing or the standard you work to.

Why buy it from Ebocom

Indoor and LSZH cable production with flame-retardant material verified in our own lab

In-house performance laboratory attenuation, tensile, crush, temperature cycling and water penetration testing on every batch

Production capacity up to 100 km per day, so large project quantities keep their delivery date

Full OEM / ODM support fiber type, sheath material, print marking, drum length and packaging to your specification

Export experience across telecom operators, power utilities and distributors worldwide, with document and logistics support
