Indoor Fiber Optic Cable 6 Core OM3 OM4 OM5 Flame Retardant Distribution Fiber Cable for Network Cabling

6 core · OM3 · flame retardant

6 Core Underground mine
Request a quote All products
Indoor Fiber Optic Cable 6 Core OM3 OM4 OM5 Flame Retardant Distribution Fiber Cable for Network Cabling

01

Product description

Indoor Fiber Optic Cable is designed for high-speed indoor communication networks, data centers, LAN systems, and building distribution applications. This distribution fiber optic cable supports 6 core, 8 core, and 12 core configurations with OM1, OM2, OM3, OM4, and OM5 multimode fiber options. The cable adopts a compact distribution structure with strong aramid yarn reinforcement and a durable outer jacket, providing excellent mechanical protection, easy installation, and stable optical transmission performance.

02

Key features

  • Available in 6 core, 8 core, and 12 core fiber counts
  • Supports OM1 / OM2 / OM3 / OM4 / OM5 multimode fiber
  • Compact distribution cable design for indoor installation
  • High strength aramid yarn reinforcement
  • Low insertion loss and stable transmission performance
  • Easy termination and installation

03

Applications

  • Underground coal mine and tunnel communication
  • Shaft, roadway and belt conveyor monitoring
  • Industrial plants with flame-retardant cabling requirements
  • Mine automation, SCADA and video surveillance networks

04

Technical specifications

ItemSpecification
Product NameIndoor Distribution Fiber Optic Cable
Fiber TypeOM1 / OM2 / OM3 / OM4 / OM5 Multimode Fiber
Fiber Count6 Core / 8 Core / 12 Core
Cable StructureDistribution Type
Fiber ModeMultimode 50/125μm or 62.5/125μm
Strength MemberAramid Yarn
Outer JacketPVC / LSZH
Jacket ColorOrange / Aqua / Violet / Lime Green (According to Fiber Type)
InstallationIndoor Application
Operating Temperature-20℃ to +70℃
CustomizationAvailable

Other fiber counts, sheath materials and drum lengths are produced to order — send us the line drawing or the standard you work to.

05

Why buy it from Ebocom

01

Mining cable built to underground safety requirements, with flame-retardant testing before shipment

02

In-house performance laboratory attenuation, tensile, crush, temperature cycling and water penetration testing on every batch

03

Production capacity up to 100 km per day, so large project quantities keep their delivery date

04

Full OEM / ODM support fiber type, sheath material, print marking, drum length and packaging to your specification

05

Export experience across telecom operators, power utilities and distributors worldwide, with document and logistics support
